07 February 2025
I am relying on Ollama for my day-to-day work. I don’t want all of my data to travel outside and therefore I really appreciate this project to run LLMs locally. With a MacBook Pro M3 with 18GB RAM, this tends to run really well for models with a reasonable parameter size.
I wanted to understand how good these models are at generating code, to maybe use them as local coding assistants, so I gave them a simple task:
“Provide complete working code for a realistic looking tree in Python using the Turtle graphics library and a recursive algorithm.”
After running the code that is generated - although not very scientific - I think the quality of the code can already be judged by the output. Besides the local models, I also let the prompt run against some online models that of course have many more parameters.
import turtle
# Setup the window
screen = turtle.Screen()
turtle.bgcolor("white")
screen.title("Realistic Tree")
# Set up the turtle
pen = turtle.Turtle()
pen.speed(10)
pen.color("brown")
pen.width(2)
# Function to draw a tree trunk
def draw_trunk(length):
if length > 5:
pen.forward(length)
pen.right(30)
draw_trunk(length - 15)
pen.left(60)
draw_trunk(length - 15)
pen.right(30)
pen.backward(length)
# Function to draw a tree
def draw_tree(depth, length):
if depth > 0:
draw_trunk(length)
pen.left(20)
draw_tree(depth - 1, length * 0.8)
pen.right(40)
draw_tree(depth - 1, length * 0.8)
pen.left(20)
pen.backward(length)
# Call the function to start drawing the tree
draw_tree(5, 100)
# Keep the window open until manually closed
screen.mainloop()
import turtle
def draw_tree(turtle, length, angle):
if length > 5:
# Draw the trunk of the tree
turtle.forward(length)
# Turn left to make a branch
turtle.left(angle)
draw_tree(turtle, length * 0.8, angle - 10) # Recursive call for the left branch
# Move back to the root of the current subtree
turtle.right(2 * angle)
# Draw the other branch
draw_tree(turtle, length * 0.8, angle - 10) # Recursive call for the right branch
# Turn back to face the original direction
turtle.left(angle)
# Move back to the root of the current subtree again
turtle.backward(length)
def main():
# Set up the turtle screen
window = turtle.Screen()
window.bgcolor("green")
# Create a Turtle object
tree_turtle = turtle.Turtle()
tree_turtle.speed(0) # Set the speed to maximum
# Start drawing the tree
draw_tree(tree_turtle, 100, 45)
# Hide the turtle and keep the window open
tree_turtle.hideturtle()
window.mainloop()
if __name__ == "__main__":
main()
import turtle
import random
# Set up the screen
screen = turtle.Screen()
screen.bgcolor("black")
pen = turtle.Turtle()
# Function to draw a tree recursively
def draw_tree(branch_len, t):
if branch_len > 5:
# Draw branch down
t.forward(branch_len)
t.color("saddlebrown")
angle = random.randint(15, 40) # Random angle for branches
shorten_by = random.uniform(0.7, 0.8) # Random shortening factor
t.right(angle)
draw_tree(branch_len * shorten_by, t)
# Draw branch left
t.left(2 * angle + 5)
draw_tree(branch_len * shorten_by, t)
# Return to the starting position
t.right(angle)
t.backward(branch_len)
t.color("green") # Reset color to green for leaves
# Set up initial conditions
pen.speed(0)
pen.left(90) # Starting angle
pen.up()
pen.backward(150) # Move the starting position down
pen.down()
# Draw the tree
draw_tree(80, pen)
# Hide the turtle and display the result
pen.hideturtle()
turtle.done()
import turtle
# Set up the screen
screen = turtle.Screen()
screen.bgcolor("white")
# Create a turtle named 'tree'
tree = turtle.Turtle()
tree.speed(0) # Fastest drawing speed
tree.color("brown")
tree.penup()
tree.goto(0, -200) # Move the turtle to the base of the tree
tree.pendown()
# Function to draw the tree recursively
def draw_tree(branch_length, t):
if branch_length > 5:
t.forward(branch_length)
t.right(20) # Turn right by 20 degrees
draw_tree(branch_length - 15, t) # Recursive call for the right subtree
t.left(40) # Turn left by 40 degrees to create a split
draw_tree(branch_length - 15, t) # Recursive call for the left subtree
t.right(20) # Turn right back to original direction
t.backward(branch_length) # Move backward to return to previous position
# Draw the tree with an initial branch length of 100
draw_tree(100, tree)
# Hide the turtle and display the window
tree.hideturtle()
turtle.done()
70b parameters is too large for my machine and thus also not usable as a local coding assistant. It was running for over an hour and only produced:
import turtle
import turtle
def draw_tree(t, branch_length, angle, shrink_factor, min_length):
"""
Draw a tree by recursively drawing branches.
Args:
t (turtle.Turtle): The turtle object used for drawing.
branch_length (float): The length of the current branch.
angle (float): The angle at which the next branch is drawn.
shrink_factor (float): The factor by which each branch is reduced in size.
min_length (float): The minimum length of a branch before it stops being drawn.
"""
if branch_length < min_length:
return
t.forward(branch_length)
t.left(angle)
draw_tree(t, branch_length * shrink_factor, angle, shrink_factor, min_length)
t.right(2 * angle)
draw_tree(t, branch_length * shrink_factor, angle, shrink_factor, min_length)
t.left(angle)
t.backward(branch_length)
def main():
window = turtle.Screen()
window.bgcolor("white")
my_turtle = turtle.Turtle()
my_turtle.speed(0) # fastest speed
my_turtle.color("green") # green color
draw_tree(my_turtle, 100, 30, 0.7, 5)
window.mainloop()
main()
import turtle
# Define constants for parameters
TRUNK_LENGTH = 100
BRANCH_LENGTH = 80
LEAF_LENGTH = 20
ANGLE = 35
def draw_branch(length):
if length > 4:
turtle.forward(length)
turtle.right(ANGLE)
draw_branch(length - 20)
turtle.left(2 * ANGLE)
draw_branch(length - 20)
turtle.backward(length)
turtle.left(ANGLE)
def draw_leaf():
for _ in range(3):
turtle.forward(LEAF_LENGTH)
turtle.right(120)
turtle.forward(LEAF_LENGTH)
turtle.left(120)
def draw_tree(length=TRUNK_LENGTH):
turtle.penup()
turtle.goto(-150, TRUNK_LENGTH / 2)
turtle.pendown()
turtle.pencolor("brown")
turtle.fillcolor("green")
turtle.begin_fill()
turtle.right(45)
turtle.forward(length)
turtle.right(-90)
draw_branch(BRANCH_LENGTH)
turtle.end_fill()
def main():
turtle.bgcolor("skyblue")
turtle.speed(1)
draw_tree()
turtle.hideturtle()
turtle.done()
if __name__ == "__main__":
main()
import turtle
# Function to draw a tree
def draw_tree(length, angle):
if length > 10:
# Move the turtle forward by specified length
turtle.forward(length)
# Turn the turtle right by specified angle
turtle.right(angle)
# Recursive call for the right sub-tree
draw_tree(0.7 * length, angle)
# Turn the turtle left by 2 times the specified angle
turtle.left(2*angle)
# Recursive call for the left sub-tree
draw_tree(0.7 * length, angle)
# Turn the turtle right by specified angle to return to original direction
turtle.right(angle)
# Move the turtle backward by specified length
turtle.backward(length)
# Set up the screen and turtle for drawing
turtle.speed('fastest') # Set the speed of drawing to fastest
turtle.left(90) # Turn turtle left by 90 degrees
draw_tree(100, 30) # Start drawing tree with initial length and angle
turtle.done() # Keeps the window open until it's manually closed
import turtle
import random
# Screen setup
screen = turtle.Screen()
screen.setup(500, 500)
screen.title("Realistic Tree")
screen.tracer(0) # Disable animation for faster drawing
# Turtle setup
pen = turtle.Turtle()
pen.speed(1) # Set turtle speed to slow
pen.hideturtle()
pen.penup()
pen.color("brown")
pen.shape("turtle") # Optional: Change pen shape
def draw_branch(angle, length, depth):
"""Recursive function for drawing branches."""
if depth <= 0:
return
pen.pendown()
pen.forward(length)
pen.left(angle)
draw_branch(angle-15, length*random.uniform(0.75,1), depth - 1) # Adjust angle and random length for variation
def draw_leaves(depth):
"""Recursive function for drawing leaves."""
if depth <= 0:
return
pen.penup()
pen.color("green")
pen.forward(50)
pen.left(180)
pen.pendown()
# Repeat the process with smaller angles and depths to create a tree-like structure
draw_leaves(depth-1)
# Main function
def draw_tree():
"""Generates a tree using recursion."""
# Draw the trunk (add your own details for more realism, like trunk color, bark texture)
pen.pendown()
pen.color("brown")
pen.begin_fill()
pen.goto(0, -100) # Place trunk here
pen.end_fill()
draw_leaves(5)
# Draw the branches (recursive calls for variation in size and angle)
draw_branch(90, 200, 1)
turtle.done()
import turtle
import random
# Screen setup
screen = turtle.Screen()
screen.bgcolor("lightgreen")
# Turtle setup
pen = turtle.Turtle()
pen.speed(0)
pen.hideturtle()
pen.penup()
# Tree drawing function (recursive)
def draw_tree(branch_len, angle):
if branch_len > 5:
pen.pendown()
pen.forward(branch_len)
# Randomly vary branch thickness for realism
pen.pensize(random.randint(1, 3))
# Draw branches recursively
pen.left(angle)
draw_tree(branch_len - 10, angle - 5)
pen.right(2 * angle)
draw_tree(branch_len - 10, angle - 5)
pen.left(angle)
pen.penup()
pen.backward(branch_len)
pen.pendown()
# Starting tree drawing
pen.goto(0, -200)
draw_tree(100, 30)
# Keep the window open until it's closed manually
turtle.done()
Here again, my hardware is not large enough to run this in sufficient time.
The performance was great, it produced some code, but the code did not run. The code seems to be… a lot.
import turtle
import random
def draw_tree(turtle_obj, x, y, length=100, angle_range=(25, 45)):
# Move the turtle to the starting position
turtle_obj.penup()
turtle_obj.goto(x, y)
turtle_obj.setheading(90) # Point upwards initially
# Draw the trunk (first line segment)
turtle_obj.pendown()
turtle_obj.width = 15 # Width of the trunk
turtle_obj.forward(length)
# After drawing the trunk, move to the end of the trunk
last_point = turtle_obj.position()
turtle_obj.trail() # Set the trail to track drawn lines
def draw_branch(turtle_obj, x, y, length):
if length < 10:
return # Base case: stop when branch is too small
# Calculate random angle within range
angle = random.uniform(angle_range[0], angle_range[1])
turtle_obj.penup()
turtle_obj.goto(x, y)
# Move forward to the next position
turtle_obj.forward(length)
# Turn by random angle and draw a small circle (representing leaves)
turtle_obj.setheading(90 - angle + 180) # Set direction before drawing leaves
turtle_obj.width = length * 0.5 # Smaller width for branches
# Draw left branch recursively
draw_branch(turtle_obj, x, y, int(length * 0.7))
# Draw right branch recursively (with a different angle)
angle2 = random.uniform(angle_range[0], angle_range[1])
turtle_obj.setheading(90 - angle2 + 180)
draw_branch(turtle_obj, x, y, int(length * 0.7))
# Move back to the starting position after drawing both branches
turtle_obj.pendown()
distance = abs(turtle_obj.xcor() - last_point.x) + abs(turtle_obj.ycor() - last_point.y)
turtle_obj.setheading(last_point[0] - y, last_point[1] - x)
if turtle_obj.distance(last_point) > 3:
turtle_obj.move(distance * (length / distance))
# Draw the tree
draw_branch(turtle_obj, last_point.x + (last_point.y + length), -length)
# Cleanup: hide trails and reset settings
turtle_obj.trail = None
turtle_obj hideturtle()
turtle_obj.reset heading(90)
turtle_obj.speed(None) # Optimize speed after drawing
# Setup the window
turt = turtle.Turtle()
window = turtle.Screen()
def main():
global turt
turt.speed('slowabs') # Slow speed for better visibility
# Initial parameters: starting position, trunk height, and width
turt.setworldcoordinates(-100, -40, 350, 270)
turt.penup()
turt.goto(150, -120) # Start at the bottom center
draw_tree(turt, 150, -120, angle_range=(25, 35), length=60)
window.setup(width=window.width(), height=window.height())
window.update()
if __name__ == '__main__':
main()
I then moved on to try out the remote models.
import turtle
import random
def tree(branch_length, t):
if branch_length > 5:
# Randomize the size of branches and angles to make the tree more realistic
t.forward(branch_length)
angle = random.randint(15, 45)
t.right(angle)
tree(branch_length - random.randint(10, 20), t)
t.left(angle * 2)
tree(branch_length - random.randint(10, 20), t)
t.right(angle)
t.backward(branch_length)
def main():
# Set up the screen
window = turtle.Screen()
window.bgcolor("blue")
# Create turtle
t = turtle.Turtle()
t.speed(0) # Fastest drawing speed
t.color("green")
t.left(90) # Point turtle to go upwards
t.up()
t.backward(100) # Move turtle a bit downwards to center the tree
t.down()
t.pensize(2)
# Drawing the tree
tree(100, t)
# Click on screen to exit
window.exitonclick()
if __name__ == "__main__":
main()
import turtle
import random
def draw_tree(branch_length, t):
if branch_length > 5:
t.forward(branch_length)
angle = random.randint(15, 45)
reduction = random.uniform(0.6, 0.8)
t.left(angle)
draw_tree(branch_length * reduction, t)
t.right(2 * angle)
draw_tree(branch_length * reduction, t)
t.left(angle)
t.backward(branch_length)
def main():
window = turtle.Screen()
window.bgcolor("lightblue")
t = turtle.Turtle()
t.left(90)
t.up()
t.backward(100)
t.down()
t.speed("fastest")
t.color("brown")
draw_tree(100, t)
window.mainloop()
main()
import turtle
import random
def draw_tree(t, branch_length, angle, depth):
if depth == 0:
return
# Draw the main branch
t.forward(branch_length)
# Save the current position
current_pos = t.pos()
current_heading = t.heading()
# Right sub-branch
t.right(angle)
draw_tree(t, branch_length * 0.8, angle * 0.9, depth - 1)
# Return to the saved position
t.penup()
t.setpos(current_pos)
t.setheading(current_heading)
t.pendown()
# Left sub-branch
t.left(angle)
draw_tree(t, branch_length * 0.8, angle * 0.9, depth - 1)
# Return to the saved position
t.penup()
t.setpos(current_pos)
t.setheading(current_heading)
t.pendown()
# Middle sub-branch (adds more realism)
t.left(angle / 2)
draw_tree(t, branch_length * 0.8, angle * 0.9, depth - 1)
# Return to the start of this branch
t.penup()
t.setpos(current_pos)
t.setheading(current_heading)
t.pendown()
def main():
# Set up the screen
screen = turtle.Screen()
screen.setup(800, 600)
screen.bgcolor("skyblue")
# Create the turtle
t = turtle.Turtle()
t.speed(0) # Fastest drawing speed
t.hideturtle()
# Set initial position
t.penup()
t.setpos(0, -250)
t.setheading(90)
t.pendown()
# Set color and pen size
t.color("brown")
t.pensize(10)
# Draw the tree
draw_tree(t, 120, 30, 8)
# Keep the window open
screen.mainloop()
if __name__ == "__main__":
main()
import turtle
import random
def draw_branch(branch_length, t):
if branch_length > 5:
# Adjust the thickness of the branches
t.width(branch_length // 10)
# Draw the main branch
t.forward(branch_length)
# Draw the right branch
angle = random.randint(15, 45)
t.right(angle)
draw_branch(branch_length - random.randint(10, 20), t)
# Draw the left branch
t.left(2 * angle)
draw_branch(branch_length - random.randint(10, 20), t)
# Return to the original position and angle
t.right(angle)
t.backward(branch_length)
def main():
screen = turtle.Screen()
screen.bgcolor("sky blue")
t = turtle.Turtle()
t.color("saddle brown")
t.speed(0)
t.left(90)
t.up()
t.backward(100)
t.down()
draw_branch(100, t)
screen.exitonclick()
if __name__ == "__main__":
main()
This was a fun exercise. It’s not very scientific, but nevertheless I think it gives some value. Obivously GitHub Copilot is the overall clear winner and there is no doubt why engineers like to work with it so much.
As for the local models, I think codestral with 22b parameters could work well on a little bit beefier machine to aid with local coding.
